VGOOD DH 30A LITE 2 - 4S Brushless ESC

VGOOD DH 30A LITE 2 - 4S Brushless ESC
Seller: GearBest,
Main Features:
- Uses 32-bit ARM processor which is small and light but runs rapidly
- Excellent speed control generates linear throttle responses and features throttle signal loss protection function
- Synchronous rectification, regenerative braking, energy recuperation ( compared with other kinds of ESCs, it saves more than 15% power )
- Supports and automatically detects the ordinary remote control signal and the Oneshot125 control signal
- Adjustable throttle setting, compatible with different remote control
- Adaptable timing, compatible with different motors
- Automatic power-up mode delivers great acceleration performance
- Has start-up protection function. To prevent the from damaging, the ESC will stop the motor when it is blocked or doesn't start up for a long time
- Available updates thanks to the independent intellectual rights

Specifications:
Voltage supply: 2 - 4S LiPo
Output PWM frequency: 24KHz
Control signal range: 900 - 2400us ( ordinary ); 100 - 300us ( Oneshot125 )
Throttle resolution: 1480 steps
Max. RPM: 450,000 ( 2 poles ); 150,000 ( 6 poles ); 75,000 ( 12 poles )

Specifications

General

Brand: VGOOD
Type: ESC

Dimension and Weight

Product weight: 0.008 kg
Package weight: 0.046 kg
Product size (L x W x H): 2.80 x 1.40 x 0.50 cm / 1.1 x 0.55 x 0.2 inches
Package size (L x W x H): 11.00 x 20.00 x 1.00 cm / 4.33 x 7.87 x 0.39 inches

Package Contents

Package Contents: 1 x ESC, 1 x Chinese-English Manual
