SZ-Speed 2205CS 2205 2300KV 3-4S Brushless Motor CW / CCW for RC Drone FPV Racing - 9.00 €

SZ-Speed 2205CS 2205 2300KV 3-4S Brushless Motor CW / CCW for RC Drone FPV Racing
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


SZ-Speed 2205CS 2205 2300KV 3-4S Brushless Motor CW / CCW for RC Drone FPV Racing

Specification:
Brand Name: SZ-Spped
Model: 2205CS
Item Name: 2205 2300KV 3-4S Brushless Motor
Version: CW Screw Thread / CCW Screw Thread ( Optional )
Configuration: 12N14P
Input Voltage: 3-4S Lipo
KV: 2300KV
Motor Width: 27.2mm
Motor Height: 30.8mm
Shaft Diameter: M5
Propelelr Adapter Shaft Thrad: M3
Weight: 26.5g
Recommend Propeller: 5 Inch Prop
Max. Thrust: 770g

Testing Table:

Propeller Voltage (V) Current (A) Thrust (g) RPM Power (W) Efficiency (g/W)
5045 12 1 63 6400 12 5.25
5045 12 3 165 10102 36 4.58
5045 12 5 238 12065 60 3.97
5045 12 7 311 13732 84 3.70
5045 12 9.1 375 15122 109.2 3.43
5045 12 11 439 16320 132 3.33
5045 12 13 492 17352 156 3.15
5045 12 15.1 546 18350 181.2 3.01
5045 12 17.2 610 19210 206.4 2.96
5045 12 20.6 715 20080 247.2 2.89

Package Included:
1x SZ-Spped 2205CS 2300KV Motor
1x bag of Screws
