SONY DC12V 800TVL 1/3 Inch 960H 2.1mm Lens Wide Angle CCD HD Camera For FPV Multicopter
Description:
CCD type: 1/3 "Sony 960H Exview HAD CCD II
Product Name: SONY 800TVL Camera
Signal System: PAL / NTSC
Total pixels: PAL: 1020H x 596V (61 million pixels) NTSC: 1020H x 508V (52 million pixels)
Effective pixels: PAL: 976H x 582V (57 million pixels) NTSC: 976H x 494V (48 million pixels)
Signal system: PAL / NTSC (default PAL format, choose the NTSC system)
Resolution (horizontal center): 800TVL
Degree: FOV 168 degree
Degree: FOV 168 degree
Digital Noise Reduction: 2D Digital Noise Reduction (2DNR) 0-15 16 support level can be adjusted
WDR: digital wide dynamic (adaptive gradation reproduction)
OSD menu: Support
Minimum illumination: 0.01LUX / F1.2
SNR: ≥48dB
Video output amplitude: 1.0Vp-p / 75Ω
AGC: 0.25 / 0.50 / 0.75 / 1.00 four levels can be adjusted to up to 55dB
White Balance: On / Off selectable
Backlight Compensation: high brightness backlight compensation (HLC) / Backlight Compensation
Exposure Mode: Electronic exposure
Electronic Shutter: 1/50 (1/60) - 100000 seconds
Gamma Correction: 0.45 / 1.0
Synchronization: Internal synchronization
Lens: Standard 2.1mm lens
Operating voltage: DC12V (wide voltage, measured can 7.5-13V work)
Working Current: 70mA (low power)
Working temperature: -20 â --60 â
Humidity: 0% to 98%
The latest SONY Effio-E chip solution, support OSD menu control, image crisp and clear, vivid colors,
low illumination, wide voltage, micropower, wide dynamic.
Shell Size: 32mm x 32mm
Weight: 13g
Features:The latest SONY Effio-E chip solution, support OSD menu control, image crisp and clear, vivid colors,
low illumination, wide voltage, micropower, wide dynamic.
Package Included:
1 x SONY 800TVL Camera
