RunCam Eagle 2 Pro 800TVL 16:9/4:3 Switchable FPV Camera With DVR01 Mini FPV DVR Module - 58.00 €

RunCam Eagle 2 Pro 800TVL 16:9/4:3 Switchable FPV Camera With DVR01 Mini FPV DVR Module
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €



Description:
Brand Name: Runcam
Item Name: RunCam Eagle 2 Pro 800TVL FPV Camera With DVR01 Module

Specification of RunCam Eagle 2 Pro:
Color: Red
Image Sensor: 1/1.8" CMOS Sensor
Horizontal Resolution: 800TVL
Lens: FOV 170 2.1mm @ 16:9 FOV 140 2.5mm @ 4:3
Screen Format: 16:9 / 4:3 Switchable on OSD menu
Signal System: NTSC / PAL Switchable on OSD menu
Integrated OSD: Yes
Integrated MIC: Yes
S/N Ratio >50dB
Electronic Shutter Speed: Auto
Max Gain: 1-9
Min. Illumination: [email protected]
WDR: Global WDR
Day/Night: Auto/External/Color/B&W
Power: DC 5-36V
Working Current: 12V@90mA / 5V@200mA
Housing Material: ABS
Dimensions: L28mm*W26mm*H28mm
Net Weight: 15g

Specification of DVR01 Module:

Power in: DC 3.3-5.5V
Work Current: 250mA Max
Power out: DC 5V @ Max 250mA
Video in: CVBS@1Vp-p 75Ω
Video out: CVBS@1Vp-p 75Ω
Encoder: MJPEG@AVI
Resolution: VGA@640 x 480@30(NTSC) 25(PAL)
Audio in: MIC
Micro SD Card: Max 32G
Dimension: 25 x 25mm @20 × 20 M2 holes
Net Weight: 3.5g

Features:
Screen Format: 16:9 / 4:3 Switchable on OSD menu.
Global WDR, CMOS Sensor.
INTEGRATED OSD / MIC.

Designed for Mini FPV Racing Drone ( 25*25mm @ 20*20mm M2 holes).
Lossless video output for VTX (Since it has been loaded to the DVR, it needs to synchronize the video amplification output).
Black technology, can record high-frequency vibration motor audio without access to MIC.

English Manual for RunCam Eagle 2 Pro, Click Here

Package Included:
1 x Camera
1 x Aluminum bracket
1 x Set of screws
1 x 5pin FPV silicone cable
1 x 3pin FPV silicone cable
1 x 2pin extension cord for menu cable
1 x 5D-OSD menu cable
1 x Runcam DVR01 Mini FPV DVR Module
1 x Set of M2 screws
1 x SD card protector
1 x 3pin FPV silicone cable (Female)
2 x Manual
