QX-Motor 30mm 6 Blades EDF Unit With QF1611 14000KV Brushless Motor - 14.99 €

QX-Motor 30mm 6 Blades EDF Unit With QF1611 14000KV Brushless Motor
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


QX-Motor 30mm 6 Blades EDF Unit With QF1611 14000KV Brushless Motor











Description:
Brand Name: QX-Motor
Item Name: EDF unit with brushless motor set
EDF Unit: 30mm 6 blades
Brushless Motor: QF1611-14000KV

Specifications of Motor:
KV 14000 Idle Current @10.0V 0.5A Configuration 9N6P No.of Cells(Lipo) 2S Stator Diameter 13mm Max Continuons Current(A)/60s 12A Stator Length 11mm Max Continuous Power(W)/60s 120W Motor Dimension 16x25mm Weight 19.5g

Testing Data:
Prop Volts(V) Amps(A) Watts(W) Thrust(g) Thrust(oz) Efficiency(g/w) Efficiency(oz/w) Throttle 30FAN 7.4 19.3 142.82 215 7.58 1.51 0.05 100%

Package Included:
1x QX-Motor 30MM 6 Blades EDF Unit With QF1611-14000KV Brushless Motor
