Pagoda LHCP/RHCP 60mm 5.8G 2dBi FPV Antenna SMA/RP-SMA With Case Red/Purple
Specifications
Center frequency: 5.8 GHz
Bandwidth: 500 MHz (5.55 – 6.05 GHz)
Matching: S11 < -20 dB, VSWR < 1.22 (at center frequency)
Axial ratio: < 1.3
Radiation efficiency: 95%
Polarisation: RHCP or LHCP
Weight: 6.6g
Size: 60mm x 22.5mm
Connector: SMA or RP-SMA (crimp shield + heat shrink)
Works great as both a transmitting and receiving antenna
Package Included
1 x Pagoda Antenna
1 x Case
