Original Airbot OMNIBUS F4 V6 Flight Controller Furling32 mini 45A Blheli_32 Brushless ESC with PDB for RC Drone FPV Racing - 98.00 €

Original Airbot OMNIBUS F4 V6 Flight Controller Furling32 mini 45A Blheli_32 Brushless ESC with PDB for RC Drone FPV Racing
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Original Airbot OMNIBUS F4 V6 Flight Controller Furling32 mini 45A Blheli_32 Brushless ESC with PDB for RC Drone FPV Racing


Specification:

Brand name: Airbot
Item name: OMNIBUS F4 V6 Flight Controller & Furling32 mini 45A Blheli_32 Brushless ESC & PDB

Flight controller:

User Manual,Download

OMNIBUS F4's upgrade version, using F405 and new target, with 5x UARTs now.

classic OMNIBUS design, using F4 MCU controls OSD over SPI bus, compare the first version, we added BMP280 as barometer and SD Card supports.

OSD Configuration has been incl. in Betaflight GUI.

FC incl. 5V1A BEC on board(3-6s) and 1x 8V BEC for Camera

MPU6000 at SPI bus, Ext, SPI for damped gyro

Use fir eworks v2 firmware, in CLI, set gyro_to_use = SECOND

New version with 8PIN Sh1.0 Socket, could be much easier connect to our 4in1 ESC by one cable.

On v5, we added jumpers for Current source select, please read the manual and set the jumper before using the FC.

Feature:
STM32 F405 MCU, Runs Betaflight 3.0 firmware
SBUS/PPM input (Pinheaders)
6PWM output (1-4Pinheaders and Sh1.0 Plug, 5-6 as Pinheaders)
Only 36x36mm, mount holes 30.5x30.5mm
INCL. BARO BMP280
SPI Sensor MPU6000
Flash

Furling32 mini 45A Blheli_32 Brushless ESC

New BLHELI32 ESC with F3 MCU, give more smooth control and faster responding speed.
New technology Mosfet, supports up to 50A burst and 45A continued. (ESC mounted under props, without anything covered on the ESC)

Feature:
F3(M4 Core) MCU, Runs BLHELI32 firmware, the MCU works at 108Mhz
Mosfet tested at 4S 55A, under props, nothing covered for 1min
12 x 24 mm
Supports Lipo 3-6S
Ext. cap needed(470uf 35v for 6s usage, not incl.)
Supports WS2812B LED


Package Included:
1 x OMNIBUS F4 V6 Flight Controller
4 x Furling32 mini 45A Blheli_32 Brushless ESC
1 x PDB Board
1 x Cable Wire
