JJRC JJPRO - P130 Battler 130mm RC Racing Quadcopter - ARF

JJRC JJPRO - P130 Battler 130mm RC Racing Quadcopter - ARF
Seller: GearBest,


Description:
JJRC JJPRO - P130 Battler is a real warrior, standing out from the majority.
Firstly, this can be told from its aura of solemn camouflage, the color belongs to the army. Then, its unparalleled high-performance propulsion system and unprecedented flight controller. It is a great choice for the intermediate players.

Specifications:
Premium Carbon Fiber Airframe
- The dynamic camouflage color breaks the monotony of colors in a racing drone
- 3K full carbon fiber frame, extremely light and sturdy
- Considerate modular components, easy to maintain and dismantle

1806 2300KV Motor
- The 17g high-torque motor has high-purity copper coil which significantly improves the efficiency
- High RPM bearings and rotors perform reliably, generating an amazing thrust of 200 - 350g
- Supports 2 - 3S LiPo, maximum current 13A, and 3 inch 3045 three-blade propeller

Flycolor 12A ESC
- Fairy Series 12A ESC for multicopters
- Innovative technology of current frequency conversion to drive MOSFET, being smaller, lighter and more efficient
- 8 kinds of motor timing ( 0 - 26.25 degree ) are available, offering you various choices of RPM and torque
- Original algorithms lead to fast processing speed, smooth and linear motor responses
- BLHeli firmware supports Oneshot and upgrades
- 12A maximum continuous current, 18A instantaneous current; supports 2 - 4S LiPo
- Excellent anti-blocking function
- Incorporates 5V 1A BEC and weighs 9.5g

NAZE32 SP Racing F3 DELUXE Flight Controller
- The state-of-the-art flight controller supports Oneshot ESC and more than 8-channel remote control
- Capable of running all the I/O ports at the same time
- Supports onboard black box flight logging and Oneshot ESCs
- With CleanFlight, configurable via a cross-platform GUI ( Windows / OSX / Linux )
- Developer-friendly debugging port ( SWD ) and boot mode selection
- Mini size, only 35 x 35mm, with a weight of 6g

5.8G FPV Camera Set
Contents: camera, transmitter, antenna, and cable
Size: 18 x 16.5 x 8mm ( not including antenna )
Weight: 6.8g
- Camera
Sensor: 1/3 inch CMOS
Lens: M8 800TVL
FOV: 150 degree wide-angle
TV system: NTSC / PAL switchable
Voltage supply: 3.6 - 5.5V
Channels: 40 ( including RaceBand )
- Built-in FPV Transmitter
TV system: NTSC / PAL
Output power: 25W
Operating voltage: 3.6 - 5.5V

Specification

General

Brand: JJRC
Type: Body Frame,Camera Set,ESC,Flight Controller,LED Light,Motor,Power Distribution Board,Propeller,Propeller Clip

Motor

KV: 2300KV
No. of Cells: 2 - 3S LiPo
Max. Continuous Current (A): 13A

Connectivity

Channel: No Transmitter
Transmitter Power: No transmitter included

Battery

Battery (mAh): 11.1V 850mAh
Flying Time: about 5mins
Charging Time (h): less than 120 minutes

Camera

Video Resolution: 800TVL ( horizontal resoultion )
Video Standards: NTSC,PAL

Racing Quadcopter Parameters

Wheelbase: 130mm

Dimension and Weight

Product weight: 0.600 kg
Package weight: 0.650 kg
Product size (L x W x H): 15.00 x 10.00 x 6.50 cm / 5.91 x 3.94 x 2.56 inches
Package size (L x W x H): 25.00 x 20.00 x 10.50 cm / 9.84 x 7.87 x 4.13 inches

Package Contents

Package Contents: 1 x Airframe, 4 x Motor, 4 x ESC, 1 x Flight Controller, 1 x PDB, 4 x LED Light, 1 x FPV Camera Set, 1 x Battery Set, 8 x Three-blade Propeller, 1 x Propeller Puller, 1 x Charger


Product Safety Disclaimer:
We do not accept any responsibility or liability for misuse of this or any other product. All our products are extensively tested to comply with rigorous and strict QC standards. For certain products (e.g. toys, knives, etc.), we recommend proper supervision as we cannot be held liable for misuse or accidents.

Small Parts Disclaimer:
These toys contain small parts, not for children under 3 years in case of swallowing or choking . We do not accept any responsibility or liability for misuse of this or any other product.
