HGLRC-Flipsky 6354 190KV 2650W Brushless Sensored Motor Shaft 8mm for Electric Skateboard Rc Models - 93.00 €

HGLRC-Flipsky 6354 190KV 2650W Brushless Sensored Motor Shaft 8mm for Electric Skateboard Rc Models
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Description:
Brand:HGLRC-Flipsky
No:6354,also name 6365,it is the same
Weight: 1.23 lb / 0.56 kg
Packaging weight:about 760g
Packaging size:115mm*175mm*90mm
Mainly fit for electric skateboards and electric bikes, as well as underwater propellers and robots, can be used with large aircraft models
Motor Spec:
Max Power: 2650 Watts
Motor KV:190KV
Model Type: MP S-6364(also name 6365)
Max Current: 65 Amps
Max Volts: 12S
Max Torque: 7Nm
Motor Resistance: 0.05Ohm
Recommend ESC: 3-12S 50A (FSESC4.12 50A or FSESC 6.6 60A)
Battery type: 6-10S
Diameter(mm): 63.4
Length(mm): 64
SHAFT: Diameter 8mm, 24mm length, 3x1.5 keyway slot.
Motor Wire: 130mm silicone 12AWG wire with 4.0mm Gold Bullet Connector Female.
Wire configuration:
Blue = A
Black = B
Yellow = C
Stator: 0.2mm thickness lamination japan steel
Magnet: N42SH high temp curve magnet
Sensor Wire: Standard RC Sensor Wire JST-ZH 6pin 1.5mm pitch
·Internal PCB with 120 Degree Hall Effect Sensors.
·Motor can be used with or without a sensor. Sensorless operation is most common.
·VESC Sensor Wires required to use with VESC.
·Wire configuration:
Red = 5v
White = Temp
Blue = A
Yellow = C
Green = B
Black = GND
Screws(the packaging are not included):
The screws used for the motor are M4x8mm metric bolts. Using our motor mounts, we recommend using M4x8mm Socket Cap bolts.
Package included:
1X 6364 190KV 2650W Rc Car Motor((Fits 63mm Motor Mount))
