GEPRC Mini AN-CS800 800TVL 1/3 CMOS 2.8mm 115 Degree FPV HD Camera 5V Input 25mm Mounting for FPV Racer
Description:
Brand Name: Geprc
Item Name: Mini Camera
Format: PAL/NTSC switchable
Image Sensor: 1/3'' CMOS
Effective Pixels(H X V): 1280x720
Synchronization: Internal
Min. Illumination: 0.05LUX/F1.2
Horizontal Resolution: 800TVL
White Balance: Auto
Auto Gain
Auto Backlight Compensation
Digital Noise Reduction: Yes(2D)
Gamma Correction: 0.45
Shutte: PAL 1/50~1/100,000s;NTSC 1/60~1/100,000S
S/N Ratio: >=50dB
Video Output: 1.0Vp-P75Ω
Power Supply: DC5V 1000mA
Working Voltage: DC4.5V-6V
Working Current: 135±5mA
Working Temp.: -40â~+105â
Connector: 3P 1.25mm
Size: 17.5mm x 17.5mm
Mounting Distace: 25mm
Weight: 9g
Features:
Special for FPV system on Mini FPV Racer
Micro design, super light,only 9g
HD image, low illumination level
5V Power Supply, low power consumption
Package Included:
1 x Camera
1 x Cable
2 x Replacement Monnting Base
1 x Lens Circle
1 x Screw Pack
