FPV 1/4 CMOS HD Color Camera Module 600TVL 120 Degree Wide Angle

Description:
Item NO.:RS-HD3918C25-12V
Sensor: 1/4 inch HD Color CMOS
Format: PAL/NTSC
Effective pixel: PAL=720(H)*576(V)/NTSC=720(H)*487(V)
Definition: 600TVL Lines
Minimum brightness: 0.01lux
View angle: 120degree
AV output: 1.0Vp-p/75Ω
Power consumption: 95mA+/-10%
SNR: >50DB
Electronic shutter: (N)1/60-1/10000s, (P)1/50-1/10000s
Work voltage: DC5-15V +/-10%
Dimension: 21*21*28mm
Work environment: 0℃~45℃ RH95% Max
Weight: 15g
Lens:2.5MM color full glass 120 degrees wide angle lens, M12 thread.
Can direct connected to the FPV 5.8G TS832.

The color of the cable definition:
Red line : DC 12V
Black line : negative and video GND
White line : AV signalFPV 1/4 CMOS HD Color Camera Module 600TVL 120 Degree Wide Angle

Package includes:
1 x 1/4 CMOS HD Color Camera Module
