DZ180 180mm FPV Racing Drone - PNP

DZ180 180mm FPV Racing Drone - PNP
Seller: GearBest,


Specifications:
dys BX1806 Motor
KV: 2700
Stator diameter: 18mm
Stator length: 6.0mm
Shaft diameter: 2.0mm
Motor dimension: 23 x 17.5mm ( diameter x height )
No. of cells: 3 - 4S LiPo
Weight: 22g
Max. continuous current: 18.2A
Max. continuous power: 305.8W
Internal resistance: 0.14 ohm

dys XM20A ESC
Input voltage: 3 - 4S LiPo
BEC: no
Function: Oneshot125
Type: BLHeli bootloader and firmware
Weight: 5.8g
Size: 24 x 14 x 4.5mm

SP Racing F3 Acro
STM32F303 CPU, 72MHz inc FPU
High-capacity flash
MPU6050 accelerometer / gyro
Dimension: 3.5 x 3.5cm
Weight: 6g

Camera
Recording resolution: HD 720P ( 1280 x 720 )
Recording frame rate: 30fps
Recording format: avi
AV output: VGA 640 x 480
Angle of view: 100 degree
Min. illumination: 1 lux
Power supply: 7 - 16V 2 - 4S battery
Consumption current: 280mAh when recording
SD card support: max. 32GB

Video Transmitter
Channels: 40 ( including RaceBand - Band 4 )
Transmit power: 200mW
Transmission distance: 500 meters in open air
Weight: 12g
Dimension: 51 x 20mm

Operation Instruction:
- How to change frequencies ( bands / channels )
Press "Band / Channel" once to change channels; push and hold the button for 2 seconds to change bands.
- How to record
After power-up, record LED turns red for standby, press "Record" to start recording, and the red LED will continue twinkling. Press "Record" again to stop recording and save.

Specification

General

Type: Frame Kit

Racing Quadcopter Parameters

Wheelbase: 180mm

Motor

Model: BX1806
KV: 2700
Stator Diameter: 18mm
Stator Length: 6.0mm
Shaft Diameter: 2.0mm
Motor Dimensions: 23 x 17.5mm ( diameter x height )
No. of Cells: 3 - 4S LiPo
Max. Continuous Power (W): 305.8W
Internal Resistance: 0.14 ohm
CW / CCW: CCW,CW
Operating Voltage / Current: 18.2A

Camera

Video Resolution: HD 720P ( 1280 x 720 )
External Memory: Micro SD card up to 32GB (not included)

Electronic Speed Controller

Firmware: BLHeli
Functions: Oneshot125
Continuous Current : 20A

Dimension and Weight

Product weight: 0.360 kg
Package weight: 0.650 kg
Product size (L x W x H): 17.50 x 14.50 x 5.80 cm / 6.89 x 5.71 x 2.28 inches
Package size (L x W x H): 20.00 x 19.00 x 9.00 cm / 7.87 x 7.48 x 3.54 inches

Package Contents

Package Contents: 1 x DZ180 FPV Racing Drone ( including 1 x Frame Kit, 4 x BX1806 Motor, 4 x XM20A ESC, 1 x SP Racing F3 Acro Flight Controller, 1 x FPV Camera with Integrated Video Transmitter, 4 x Propeller, 1 x Mushroom Antenna )

Product Safety Disclaimer:
We do not accept any responsibility or liability for misuse of this or any other product. All our products are extensively tested to comply with rigorous and strict QC standards. For certain products (e.g. toys, knives, etc.), we recommend proper supervision as we cannot be held liable for misuse or accidents.

Note:
Product photography is for illustration only. The product sold may have minor physical differences depending on manufacturer specifications, production batch, etc. Customers should carefully consider this before purchase.

Small Parts Disclaimer:
These toys contain small parts, not for children under 3 years in case of swallowing or choking . We do not accept any responsibility or liability for misuse of this or any other product.
