CL Racing F4 Flight Controller V2 AIO OSD BEC Current Sensor SD Card Slot Support TP Smartaudio VTX - 28.00 €

CL Racing F4 Flight Controller V2 AIO OSD BEC Current Sensor SD Card Slot Support TP Smartaudio VTX
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


CL Racing F4 Flight Controller V2 AIO OSD BEC Current Sensor SD Card Slot Support TP & Smartaudio VTX

Notice: Not Included the yellow anti-vibration Rubber Damping Balls

Specification:
Item Name: Betaflight F4 Flight Controller AIO OSD BEC & Current Sensor
Input Voltage: 2-6S Lipo support
CPU: STM32F405RGT6
MPU: MPU6000
Firmware: Betaflight CLRacingF4
Recommend Flash " betaflight_3.1.7_CL_RACINGF4-v2.hex "
BEC Output: 3.3V / 5V /7.6V @ 1.2A
- PCB Support con. current 120A , Max. 240A
- Build-in Betaflight OSD
- Build-in Current Sensor
- Build-in SD Card Slot, Blackbox support max. 32G storage
- Onboard Buzzer
- 3 UART + USB, Support SBUS / IBUS/ SAT/ PPM Receiver
- 5V LED Strip
- Support TP and Smartaudio VTX
- DShot ready for new ESC protocol
Size: 36x36mm
Mounting Hole: 30.5x30.5mm
Pacakge Included:
1x CL Racing F4 Flight Controller
