Specification:
Item name: 2.4G 8/18CH PPM S.BUS AFHDS 2A Receiver
Channel: PPM 8CH, S.bus 18CH
Frequency range: 2.408-2.475GHz
Number of signal channels: 135
Receiver sensitivity: -92dBm.
2.4G protocol: AFHDS 2A
DSC interface: PPM & S.bus
Antenna length: 32mm
Input voltage range: 4.5-8.0V
Control distance: >400 meters
Working current: 35 mA
Size: 26.5*13.5mm*3.0mm
Weight: 3 g
Feature:
- With automatic code matching/frequency mode, the receiver pair code line or code button switch is cancelled
- The first 3 seconds of power-on is automatically in the flashing code mode. When matching the remote control for the first time, you only need to press and hold the BIND button on the remote control to achieve the code/frequency operation
- Compatible with Flysky I6, FS-I6X, FS-I6X, FS-I8, FS-I10, etc. The standard interface supports PPM and S.BUS protocols.
- The ground level is more than 300 meters. The air distance is more than 500 meters.
Package Included:
1 x 2.4G 8/18CH PPM S.BUS AFHDS 2A Receiver
