WolfBox 1000mW 1W 433MHz Long Range UHF Transmitter TX 100mW Receiver RX Combo for X9D X12S 9XR
Description:
WOLFBOX LONG RANGE UHF TX
Channel: Default 8CH, Max. 16CH(Users can customize)
Frequency: 416-463MHz
Transmission Power:1W
Working Voltage: 6.5-28V Wide Voltage Input
Input Signal: PPM
Programme Method: Bluetooth serial port, software programe
Transmission Distance: Depends on the antenna
Compatible with Frsky X9D,X12S,9XR,9XR PRO,Flysky 9,JR 9XII etc. JR Module
WOLFBOX LONG RANGE UHFRX
Channel: Default 1-8CH+RSSI, Max. 16CH(Users can customize)
Frequency: 416-463MHz
Transmission Power:100mW
Working Voltage: 4-6.5V
Configuration: Adjust parameter by wireless transmission
Transmission Distance: Depends on the antenna
WOLFBOX 433 Distance Testing:
http://v.youku.com/v_show/id_XMTQ0NTM2MTkyMA==.html
Basic Setting and Loss Control Protection:
http://v.youku.com/v_show/id_XMTQ0ODUzNjcwMA==.html
CLI Adjusting Parameter
http://v.youku.com/v_show/id_XMTQ1NDAxMzUwNA==.html
Function and Tool
http://v.youku.com/v_show/id_XMTQ4MTIxNzYzNg==.html
http://pan.baidu.com/s/1mht0zxQ
Package Included:
1 x WOLFBOX 433 TX
1 x WOLFBOX 433 RX
2 x Antenna
