SunriseModel BLHeli-S 25A Brushless ESC

SunriseModel BLHeli-S 25A Brushless ESC
Seller: GearBest,

Main Features:

- Designed for superior performance in multirotors
- Uses PWM signals to produce smooth and linear throttle response
- Damped light regenerates braking, greatly shortening motor retardation, which is ideal for freewheeling
- The BLHeli-S firmware helps prevent sync loss
- Parameters can be set to that run the firmware in the most demanding situations, although default settings work excellently in normal operating environments
- Supports regular 1 - 2ms pulse width input, as well as Oneshot125 ( 125 - 250us ), Oneshot42 ( 41.7 - 83.3us ) and Multishot ( 5 - 25us )
- The input signal is automatically detected by the ESC upon power-up

Brand name: SunriseModel
Item name: BLHeli-S 25A ESC
Continuous current: 25A
Peak current ( 10 seconds ): 30A
Input voltage: 2 - 4S
BEC: no
Programmable: yes
Firmware: BLHeli-S
Compatibility: 180 - 250mm RC multicopters
Size: 28 x 13 x 5.5mm ( not including wires )
Weight: 8.5g



Brand: SunriseModel
Type: ESC

Dimension and Weight

Product weight: 0.008 kg
Package weight: 0.044 kg
Product size (L x W x H): 2.80 x 1.30 x 0.55 cm / 1.1 x 0.51 x 0.22 inches
Package size (L x W x H): 11.00 x 22.00 x 2.00 cm / 4.33 x 8.66 x 0.79 inches

Package Contents

Package Contents: 1 x ESC, 1 x Chinese-English Manual
