RRUISSI R2205 2205 2500KV 3-4S Brushless Motor for RC Drone FPV Racing
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €

RRUISSI R2205 2205 2500KV 3-4S Brushless Motor for RC Drone FPV Racing




Specification:
Brand name: RRUISSI
Item name: R2205 2500KV Brushless Motor
KV: 2500
Motor dimension(Dameter*Length): 28*32.5mm
Shaft Diameter of propeller adapter: M5
Motor mounting holes(pitch,size): 16mm, 29mm 4-M3 screws
Stator diameter: 22mm
Stator length: 5mm
Net. Weight of motor: 29g
Configuration: 12N14P
Rated voltage: 12-16V
Rated current: 35A
Rated power: 500W
Max continuous current: 27A
Max continuous power: 560W
Idle current (No load current@12V): 0.4A
Motor efficiency: 90%
No. of celles: 3-4S
Internal resistance: 62mΩ
Dynamic balanced rotor: Y
Heavy duty design: Y
Electronic speed controller-ESC(Recommended only): 3-4S/ 30A ESC
Propeller: 4s: 5*4.5/ 6*3.5

Package Included:
1 x R2205 2500KV Brushless Motor
