Matek System 20x20mm F411-mini Mini F4 Flight Controller AIO OSD BEC and LED Strip
Specification:
Brand Name: Matek
Item Name: 20x20mm Mini F4 Flight Controller AIO OSD BEC and LED Strip
MCU: 100MHz STM32F411
IMU: MPU6000
IMU: MPU6000
OSD: BetaFlight OSD w/ AT7456E chip
Camera control supported on Rssi pad
Battery Voltage Sensor: 1:10
Current Sensor: No (FCHUB-A option)
BEC: 5V 2A
LDO 3.3V: Max.300mA
I2C1 SDA & SCL available
WS2812 Led Strip : Yes
Built in inverter for SBUS input (UART1-RX)
PPM/UART Shared: UART2-RX
SoftSerial supported on S5 & S6
Beeper : Yes
RSSI: No
Blackbox: No
Size: 28x28mm Mounting Hole: 20x20mm
Weight: 4.5g
Features:
- 20x20mm Mounting hole, only 4.5g
- with betaflight OSD and 5V BEC output
- with 2 LED indicator, blue and red
- Built in inverter for SBUS input (UART1-RX)
- PPM/UART Shared: UART2-RX
Package Included:
1x F4 Flight Controller
6x Silicon grommets M4 to M3
6x Brass grommets M3 to M2
Package Included:
1x F4 Flight Controller
6x Silicon grommets M4 to M3
6x Brass grommets M3 to M2
