ImmersionRC Raceband 5.8GHz 25mW A/V Transmitter For FatShark
This ImmersionRC Audio / Video Transmitters provides a clean and powerful transmission
100% compatible with all Fat Shark and Immersion RC products.
Strong penetration and a locked in signal gives you the best picture on 5.8GHz all in a lightweight,
powerful, 25mW 5.8GHz transmitter
Description:
Item Name: 5.8GHz 25mW A/V Powerful Transmitter
Input voltage range: 6 – 25V (2S-6S)
Connector: SMA Famale
Clean output power: 25mW (+/- 1dB)
Features:
1. 37MHZ frequency seperation allows for flying up to 8 pilots simultaneously
2. Onboard quiet switching regulator, powers 5V cameras
3. Not affected by 2.4GHz R/C radios!
4. Frequencies: 5740, 5760, 5780, 5800, 5820, 5840, 5860 MHz (ImmersionRC/FatShark)
All standard channels within the US/EU ISM Band
5. Frequencies: 5658, 5695, 5732, 5769, 5806, 5843, 5880, 5917MHz (RaceBand)
All Raceband channels legal using a Ham license within the USA
6. Raceband Channels 1-6 legal using a Ham license within the EU
Package Included:
1 x ImmersionRC Raceband 5.8GHz 25mW A/V Powerful Transmitter
1 x 2.15dBi 5.8GHz omni-directional antenna (SMA male connector)
1 x Video cable (20cm 5-pin Molex-SL terminated in wire ends)
1 x DC power cable (24cm 2-pin Molex-SL terminated in BEC-style connector)
