GDW DS396MG 12KG Large Torque High Voltage Metal Gear Digital Servo for RC Models - 36.00 €

GDW DS396MG 12KG Large Torque High Voltage Metal Gear Digital Servo for RC Models
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


Specification:


Brand: GDW

Model: DS396MG





Bench tests reported values
Test Voltage6.0V 7.4V8.4V
Speed0.128sec/60°0.10sec/60°0.093sec/60°
Torque9.0Kg.cm11.3Kg.cm12.9Kg.cm
Fast continuous operating current700mA850mA1000mA
Stall current1800mA2000mA2300mA
Dead Band Width3u
General Data
Motor Type: Coreless motor 15*15mm
Potentiometer Type:Japan noble 220°
Chip type:Digital
Weight:39±1g
Gear Material:Iron copper gear
Structural materials : Internediate metal
Horn Gear Spline:25T 5.92mm
Wire length:220±5mm
Wire Diameter:0.15mm*
Number of wire cores:30




Package included:


1*GDW DS396MG Servo
