FPV Multi-camera Mini Two-way Electronic Switch Video Switcher Module

No OSD Wiring Method 1:


No OSD Wiring Method 2:


With OSD wiring method 1:



With OSD wiring method 2:



Description:
Item Name:AV Video Switcher
Video Switcher Board Size (Not Included Pins):16 x16mm
Weight:1g

Features:
Enjoy the perspective of different directions
You can switch the two cameras or AV signals of DV by controlled transmitter,were respectively switched to the OSD or video transmitter.
Dedicated video switching IC, no loss of quality, no switching life, ultra-small resistance
It can work with 3.3-12V camera .

Notice:
Video switcher can access any channel receiver to use, practical advice to use two-way switch or knob channel to use.
AV_IN1 and AV_IN2 for two-way video input
AV_OUT for video outputs
PWM Connect the receiver to any channel
5V connected receiver 5V
GND connected ground line of receiver

Please be careful that the wiring sequence when use it, video switching module itself is power supply by the receiver 5V, 12V not access the video wire.

Indicator Explanation:
Long bright--Module’s PWM signal input is abnormal--AV_IN1 communicate with AV_OUT
Quick flash--Module’s PWM signal input is normal--AV_IN1 communicate with AV_OUT
Slow flash--Module’s PWM signal input is norma--AV_IN2 communicate with AV_OUT


Package Included:
1x AV Video Switcher (Not Included Receiver)
