FPV 1/3 Inch HD Color CMOS 600TVL Mini Camera PAL - 19.99 €

FPV 1/3 Inch HD Color CMOS 600TVL Mini Camera PAL
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


FPV 1/3 inch HD Color CMOS 600TVL Mini Camera




Description:
Image Sensor 1/3 inch HD Color CMOS Horizontal Resolution 600TV Line Effective Pixel 768(H)×576(V) Minimum Illumination 0.008Lux Angle 60 Degree Signal system PAL Back Light Compensation Auto Gamma 0.5 S/N Ratio More than 50db (AGC-OFF) Scanning System 2:1 Internal Synchronization System Internal Synchronization Shutter Speed (N)1/60-1/10000s, (P)1/50-1/10000s Video Output 1.0Vp-p/75Ω Power Supply DC 3.3V- 5V Operation Temperature -10C ~ 50C / 0F ~ 110 F Dimensions 21*21*28mm Weight 18g

Product review from customer:
A great little camera - Ideal for FPV Post on March 25,2014 15:36 by HeliEye

I received 2 of these small camera's yesterday morning, which was quick delivery. I usually have reservations about spec's from China, which some time can get a little exaggerated, these state 600TVL, so I tested against a 'known' 700TVL camera, and these were very close in video quality, so full marks for accurate specs. There seems to be a lot of confusion about what volts these run at?? the Spec says 3.3v to 5v, which IS correct. I have tested from 3.3v to 5v with no problems. This camera is ideally suited to run of a single cell LiPo, the size of the battery can be Very small, as the camera only draws about 70mA. So this camera is pretty much perfect for FPV.. the camera at 18gms Plus a small single cell LiPo, I'm using a 550mA LiPo, just because I had 4 in stock, this weighs 20.1gms, so 38gms for cam & battery is light weight. This LiPo would power the camera for 7.8 Hours, so over-kill. A 110mA LiPo would be better, if lower weight is important, still with a 1.5 hour run time. Also note: The lens is a standard MTV lens, so lenses can be changed to suit your needs. I Hope the info helps. Steve
for more details:

For this camera in NTSC ,.

Package included:
1 x 600TVL Camera
1 x Cable
