FOXEER 5.8G 3dBi Omnidirectional RHCP Antenna

FOXEER 5.8G 3dBi Omnidirectional RHCP Antenna
Seller: GearBest,


Main Features:
- 5.8G fast transmission, real-time FPV
- SWR less than 1.5, tuned for 5600 - 5950MHz
- Omnidirectional 3dBi antenna, wide signal coverage in a given area

Specifications:
Item: 5.8G 3dBi omnidirectional antenna
Frequency range: 5600 - 5950MHz
Gain: 3dBi
Weight: 12g
SWR: less than 1.5, tuned for 5600 - 5950MHz
Max. power: 50W
Resistance: 50 ohm
Polarization: RHCP
Connector: RP-SMA / SMA
Color: green / red / black
Horizontal lobe width: 360 degree
Vertical lobe width: 120 degree
Lightning protection: DC grounded
Dimension ( height x diameter ): 105 x 35mm ( feeder line 75mm )

Specification

General

Brand: FOXEER
FPV Equipments: FPV Antenna

Dimension and Weight

Product weight: 0.012 kg
Package weight: 0.038 kg
Product size (L x W x H): 10.50 x 3.50 x 3.50 cm / 4.13 x 1.38 x 1.38 inches
Package size (L x W x H): 12.00 x 17.00 x 4.00 cm / 4.72 x 6.69 x 1.57 inches

Package Contents

Package Contents: 1 x FPV Antenna
