FLYSKY FS - i6X Transmitter

FLYSKY FS - i6X Transmitter
Seller: GearBest,


Description:
The AFHDS 2A developed by FLYSKY is intended for all radio control models. It offers superior protection against interference while maintaining lower power consumption and highly reliable receiver sensitivity.

Main Features:
Two-way Communication
Capable of sending and receiving data, the transmitter can receive data from the temperature sensor, barometer, accelerometer and etc.

Multi-channel Frequency Hopping
Ranging from 2.408GHz to 2.475GHz, the bandwidth is divided into 135 channels to minimize the interference from other transmitters.

Omnidirectional Antenna
The omnidirectional high gain antenna reduces interference while using less power and maintaining a reliable connection.

Unique ID Recognition System
Each transmitter and receiver have its own unique ID. The paired units will connect automatically with each other for the second time.

Low Power Consumption
It only consumes about one-tenth the power of a standard FM system, dramatically extending battery life.

Specifications:
FLYSKY FS - i6X Transmitter
Channels: 6 - 10 ( default: 6 )
Model type: fixed-wing airplanes / gliders / helicopters
RF channels: 135
Frequency range: 2.408 - 2.475GHz
Bandwidth: 500KHz
RF power: less than 20dBm
2.4GHz system: AFHDS 2A / AFHDS
Modulation: GFSK
Low voltage warning: less than 4.2V
DSC port: PS/2, PPM
Chargeable: no
Antenna length: 26mm ( dual antennas )
Weight: 392g
Power input: 4 x 1.5V AA ( 6V )
Display: STN LCD, 128 x 64 lattice, VA 73 x 39mm, with white backlight
Online update: yes
Certificate: CE0678, FCC

FLYSKY FS - iA10B Receiver
Channels: 10
Model type: fixed-wing airplanes / gliders / helicopters
RF range: 2.4055 - 2.475GHz
RF channels: 140
RF receiver sensitivity: -105dBm
Bandwidth: 500KHz
2.4GHz system: AFHDS 2A
Modulation: GFSK
Power: 4.0 - 6.5V DC
Antenna length: 26mm ( dual antennas )
Weight: 17.6g
Size: 50.6 x 34.9 x 14.9mm
iBus port: yes
Data acquisition port: yes
Certificate: CE0678, FCC

Specification

General

Brand: Flysky
Type: Transmitter Receiver Set

Dimension and Weight

Product weight: 0.392 kg
Package weight: 0.730 kg
Product size (L x W x H): 17.40 x 8.90 x 19.00 cm / 6.85 x 3.5 x 7.48 inches
Package size (L x W x H): 20.00 x 10.00 x 20.00 cm / 7.87 x 3.94 x 7.87 inches

Package Contents

Package Contents: 1 x Transmitter, 1 x Receiver
