CUAV SX Radio 1mW-1000mW Switched 900MHz High Power Wireless Data Transmission Module Transmitter Receiver For PIXHACK PIXHAWK
Description :
Physic :
Size : 52*39*16mm, 59*39*16mm
Weight : 39g(with antenna) 62g(without antenna)
Connector : RP-SMA
Working Temp.:ã-40â-+85â
Certification : US(FCC) OUR-9XTEND;CA(IC) 4214A-9XTEND; AU Approved(XTH9)
Specification :
Power Output : 1mW-1W(0-30dBm), switchable on software
Indoor Distance : max. up to 900m
Outdoor Distance : up to 64km(depends on the environment)
TX Transfer Rate : 9.6 or 115.2 kbps
Interface Data Transfer Rate : up to 230.4 kbps
RX Transfer Rate : -110dBm(9600bps )
Wireless Parameter :
Spread Spectrum : FHSS (Frequency-hopping)
Network Topology : DigiMesh, port to port, node to node, node to multi-node and repeater
Error Handling : Retry and confirm, multiple transmission
FOptions : VID, channel and addressing
Channel Capacity : 10 hop sequence share 50 frequencies
Address Assignment : Each channel offer 65000 network addresses
Encryption : 256 bit AES
Frequency : 902-928MHz
Seriel Data Port : 3v-5v CMOS UART- no need configure(doesn't support RS232)
Electronic :
Power Supply : 2.8-5.5 VDC
Transmitting Current : 730mA (5V,1W)
Receiving Current : 80mA (5V 1W)
Power Failure : 5ua
Features :
Adopt XTEND chip, high power, fast speed rate and high sensitivity data module.
Up to 1000mW power, ISM 900MHZ, support multiple network and topology mode
It has same function as XTEND data transmission module, but smaller and lighter.
Provide stable data transmission between drone and ground.
Package Included :
1 x Transmitter
1 x Receiver
2 x Antenna
1 x USB Cable
1 x PIXHACK Data Cable
1 x PIXHAWK Data Cable
