30.5x30.5mm Omnibus F4 Flight Controller AIO OSD 5V BEC and Current Sensor
Specification:
Item Name: Omnibus F4 FC AIO OSD BEC and Current Sensor
Mounting Hole: 30.5x30.5mm
MCU: STM32F405 , CRT6, 8K
Sensor: ICM-20608
Input Voltage: 2-6S Lipo
- BEC Output: 5V 3A
- Integrated with OSD, support BF Ground Station adjust OSD
- Built-in Current Sensot, can monitor current
Fimware: betaflihgt_3.2.0_OMNIBUSF4SD
Receiver: Support PPM, SBUS, IBUS, DSM2/ DSMX Receiver
Size: 42x36mm
Weight: 9g
Features:
- STM32F405 CRT6, refresh rate up to 8K
- PCB 3OZ copper enhance current stability and cooling fast
- 5V 3A BEC output
- Exposed pad for easy soldering
- Integrated OSD, no need to flash firmware additionally,debug OSD via BF ground station.
- Integrated current meter to monitor the real-time power consumption
- Adjust the PID by OSD via remote control
- Adjust the VTX via open ports such as power, frequency band, frequency point (Note: The VTX should have this function like TBS one and the upcoming - DYS VTX.)
- With 4 damping balls reduce the vibration to make it fly stably.
Package Included:
1x Omnibus F4 Flight Controller
4x Anti-vibration Rubber Shock Balls
Package Included:
1x Omnibus F4 Flight Controller
4x Anti-vibration Rubber Shock Balls
