700TVL 2.8mm Lens 90 Degree 1/4 Cmos Wide Angle FPV Camera NTSC PAL
Specification:
Item name: FPV Camera
Resolution: 700TVL
Camera size: 25mm*25mm
Format: PAL / NTSC
Lens: Wide-angle 2.8mm (90degree)
Power input: DC 12V
Output: 12V
Image sensor: 1/4 CMOS image sensor
System standard: PAL/NTSC PAL ( H X V ):512X 582 NTSC ( H X V ):542 X 492
Electronic Shutter: PAL= 1/50 - 1/100,000 second NTSCL= 1/60 - 1/120,000 second
Minimum illumination: 0.1Lux (F: 1.2)
SNR: > 48dB (AGC Close)
Gamma: 0.45
Automatic Gain: On / Off
Auto White Balance: On / Off
Lens Mount: C / CS
Video output: 1 Vp-p, 75Ω
Operating temperature range: -10 â to 50 â (maximum humidity 95%)
Package Included:
1 X 700TVL FPV Camera
