6M GPS Module Built-in Compass Mini APM/PIX/APM/Dupont Interface
Description:
Item Name: 6M GPS Module
Power Supply: DC Voltage 3.3~5.5V
Receiving Format: GLONASS,Galileo,BeiDou,QZSS
Receiving Channel: 72 Searching Channel,u-blox M8 engine
Receiving Sensitivity: Trace -167dBm
Receiving Sensitivity: Trace -167dBm
Capture-160dBm
Level Positioning Precison: 2m CEP
Speed Precison: 0.1 m/s
Dynamic Characteristics: Max Height:50000m
Level Positioning Precison: 2m CEP
Speed Precison: 0.1 m/s
Dynamic Characteristics: Max Height:50000m
Max Speed:500m/s
Max Acceleration:4G
GPS antenna size: 25 * 25 * 4mm
Cable length: 250mm
Weight: 30g
GPS antenna size: 25 * 25 * 4mm
Cable length: 250mm
Weight: 30g
Application:
-APM Interface: For APM2.6 /2.72/ 2.8 Flight Control
- Mini APM Interface: For Mini APM
-PIX Interface: For PIX PX4 PIXHAWK series Flight Control
-PIX Interface: For PIX PX4 PIXHAWK series Flight Control
- Dupont Line Interface: For Rabbit 1 and 2 on behalf of the pirates, MWC, APM1 flight control and other 2.54mm pitch
Features:
1. Low-power and high-precision, ultimate precision to 0.6 meters. The actual test mostly about 0.9 meters. Pix to test the accuracy of the return is mostly in between 20-30cm,relative to the previous generation of NEO-7N 1.3-1.6 meter accuracy to improve a lot.
2. The star search speed and volume improved significantly, to support Europe's Galileo, Russia's GLONASS, Japanese QZSS, Chinese BeiDou.
3. The module supports GPS + Compass + SBAS or GPS + GLONASS + SBAS. This version is built-in electronic compass, the refresh rate to 18Hz.
GPS Connector Definition:
Connector 1:
GND,Earthing
TX,Module data output
RX,Module data intput
VCC,5V
Connector 2:
Compass SCL clock pin
Compass SDA clock pin
Package Included:1 X 6M GPS Module
