3.7g 20x20mm F3 Nano 6Dof MPU6000 Omnibus F3 Flight Controller AIO OSD 5V BEC LC Filter for RC Drone - 19.00 €

3.7g 20x20mm F3 Nano 6Dof MPU6000 Omnibus F3 Flight Controller AIO OSD 5V BEC LC Filter for RC Drone
Seller: Banggood,
Free shipping aviable, Registered postage from 25 €


20x20mm F3 Nano 6Dof MPU6000 Omnibus F3 Flight Controller AIO OSD 5V BEC LC Filter for RC Drone





Specification:
Item Name: Omnibus F3 Flight Controller AIO OSD BEC and LC Lilter
CPU: STM32F303CCT6
Sensor: MPU-6000 (connected by SPI)
Firmware: betaflight_3.X.X_OMNIBUS
- Built-in Betaflight OSD
- Built-in 5V 3A BEC
- Built-in LC Lilter, support DShot ESC
Input Voltage: 2-4S
Size: 27x27mm
Mounting Hole: 20x20mm ( M2.5)
Weight: 3.7g
- Support SBUS/IBUS/PPM/DSMX Receiver
- Support 3.3V Spektrum Satellite Receiver
Application: for ≦ 150mm Frame Kit

Features:
-PPM/SBUS/DSM2/DSMX input
-LED_STRIP solder pin
-Buzzer solder pin
-With LC filter
-Built-in betaflight OSD
-Built-in voltage detection, alarm
-Support the DSHOT ESC
-Support programmable LEDSD (turn off transponder before using)
-Support BLheli suite

Package Included:
1x Omnibus F3 Flight Controller
